Electro-Voice PCPLUS5 Multi-Pattern 5" Gooseneck Microphone

The PC Plus with dual-section gooseneck is the first podium microphone that has the flexibility to be installed into any environment. Delivering RF/GSM protection via RF Shield and four switchable PC polar patterns, it can be mounted via a standard three pin XLR connector or permanently flush-mounted to a podium or tabletop.

Features:

• Easy switching between omni, cardioid, supercardioid or hypercardioid polar patterns
• Mute switch with LED can be programmed as either push on/off or push-to-mute
• Smooth, uniform frequency response in all patterns
• Extended low frequency response and switchable high-pass filter
• RF Shield guards against RF/GSM interference

Specifications:

• Generation Element: Dual condenser, back-electret
• Frequency Response: 50Hz to 20,000Hz
• Impedence: 200 ?
• Polar Patterns:
  Omnidirectional
  Cardioid
  Supercardioid
  Hypercardioid
• Switches and Controls:
  Top mounted momentary push-button
  Push on/off, or PTT/PTM selector
  Power up on/off selector
  High pass enable
  4-position polar pattern selector
• Sensitivity: Open Circuit Voltage, 1kHz:5.6mV/Pascal
• Power Requirements: Phantom, 12-52 VDC
• Connector Type: 3-pin XLR and 3-pin Phoenix
• Polarity: Pin 2 positive, referenced to Pin 3, with positive pressure on the diaphragm
• Dimensions
  Gooseneck Length: 127mm (5in.)
  Maximum Head Diameter: 14.6mm (0.58in.)
  Gooseneck Diameter: Lower section, 7.9mm (0.31in.) / Upper section, 6.4mm (0.25in.)
• Color: Non-reflecting Black
• Accessories Furnished: Windscreen, Two-piece shock mount, Flush mount parts kit
